Receptacles for connector Males for connector Male Connectors Female Connectors Retainer| Receptacles terminals UP-XM  | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Figure | Part number | Wire size mm² (AWG) | Ø Insulation (mm) | For male (mm) | Din | Brass 01 | Bronze 31 | K55 511 | Material thickness (mm) | Winding number |
  | ||||||||||
| 8701.*** | 0,25-0,50 (24-20) | 1,6 Max | 0,63x0,63 | Esp | ⬤ | ⬤ | ⬤ | 0,2 | 10000 | |
| Tabs terminals UP-XM  | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Figure | Part number | Wire size mm² (AWG) | Ø Insulation (mm) | Tongue thickness (mm) | Din | Brass 01 | Bronze 31 | K55 511 | Material thickness (mm) | Winding number |
 | ||||||||||
| 6701.*** | 0,25-0,50 (24-20) | 1,6 Max | 0,63 | Esp | ⬤ | ⬤ | ⬤ | 0,2 | 10000 | |
| UP-XM Female-Holder Connectors  | ||||
|---|---|---|---|---|
| Figure | Part number | Ways | To terminal | PA66GF30 95 |
 | 4 ways Male Connector | |||
| 232PFA04** | 4 | 8701.511 | ⬤ | |
 | 5 ways Male Connector | |||
| 232PFA05** | 5 | 8701.511 | ⬤ | |
 | 6 ways Male Connector | |||
| 232PFA06** | 6 | 8701.511 | ⬤ | |
 | 8 ways Male Connector | |||
| 232PFA08** | 8 | 6701.511 | ⬤ | |
 | 9 ways Male Connector | |||
| 232PFA09** | 9 | 8701.511 | ⬤ | |
 | 10 ways Male Connector | |||
| 232PFA10** | 10 | 8701.511 | ⬤ | |
 | 12 ways Male Connector | |||
| 232PFA12** | 12 | 8701.511 | ⬤ | |
 | 16 ways Male Connector | |||
| 232PFA16** | 16 | 8701.511 | ⬤ | |
| UP-XM Male-Holder Connectors  | ||||
|---|---|---|---|---|
| Figure | Part number | Ways | To terminal | PA66GF30 95 |
 | 4 ways Female Connector | |||
| 232PMA04** | 4 | 6701.511 | ⬤ | |
 | 5 ways Female | |||
| 232PMA05** | 5 | 6701.511 | ⬤ | |
 | 6 ways Female Connector | |||
| 232PMA06** | 6 | 6701.511 | ⬤ | |
 | 8 ways Female Connector | |||
| 232PMA08** | 8 | 6701.511 | ⬤ | |
 | 9 ways Female Connector | |||
| 232PMA09** | 9 | 6701.511 | ⬤ | |
 | 10 ways Female Connector | |||
| 232PMA10** | 10 | 6701.511 | ⬤ | |
 | 12 ways Female Connector | |||
| 232PMA12** | 12 | 6701.511 | ⬤ | |
 | 16 ways Female Connector | |||
| 232PMA16** | 16 | 6701.511 | ⬤ | |
| Retainer UP-XM  | |||
|---|---|---|---|
| Figure | Part number | Ways | PBTGF30 85 |
 | 4 Ways | ||
| 232TPA04** | 4 | ⬤ | |
 | 6 Ways | ||
| 232TPA06** | 6 | ⬤ | |
 | 5 ways | ||
| 232TPA05** | 5 | ⬤ | |
 | 8 Ways | ||
| 232TPA08** | 8 | ⬤ | |
 | 9 Ways | ||
| 232TPA09** | 9 | ⬤ | |
 | 10 Ways | ||
| 232TPA10** | 10 | ⬤ | |
 | 12 Ways | ||
| 232TPA12** | 12 | ⬤ | |
 | 16 Ways | ||
| 232TPA16** | 16 | ⬤ | |
The product with a red triangle ( ▲ ) obey the UL regulations
