Receptacles for connector
All
4.8 (.187) Type Series| H15 Lamp receptacle  | ||||||
|---|---|---|---|---|---|---|
| Figure | Part number | Wire size mm² (AWG) | Ø Insulation (mm) | Cu. Alloy 51 | Material thickness (mm) | Winding number |
  | ||||||
| 8430.** | 0,5-1 (20-18) | 2,5 Max | ⬤ | 0,32 | 3000 | |
| Receptacle Connectors | |||
|---|---|---|---|
| Figure | Part number | Ways | PBT-GF20 95 |
 | 3 ways connector | ||
| 24832** | 3 | ⬤ | |
 | H15 cover connector | ||
| 24836** | 3 | ⬤ | |
The product with a red triangle ( ▲ ) obey the UL regulations
